Description
⚡ Power & Efficiency
-
Class Nominal Power: 605–630 W, specifically rated at 610 W (±3%)
-
Module Efficiency: 22.6% (610 W); peak up to 23.3% in higher bins
-
Cell Technology: N‑type monocrystalline TOPCon cells in a 132-cell (6×22) layout
🔋 Electrical Characteristics
-
MPP Voltage/Current: ~41.31 V / 14.77 A at 610 W
-
Voc / Isc: ~48.74 V / 15.94 A at STC
-
Temperature Coefficients: –0.29%/°C (Pmp), –0.25%/°C (Voc), +0.043%/°C (Isc) — excellent heat resilience
-
System Voltage: Up to 1500 V DC; junction box rated IP68 with MC4 connectors
🧱 Structural & Mechanical Specs
-
Dimensions: 2382 × 1134 × 30 mm; weight ~32.8 kg
-
Glass–Glass Build: 2 mm tempered front and back glass on robust anodized aluminum frameMechanical Load Capacity: 5400 Pa snow (front), 2400 Pa wind (rear)
🌞 Bifacial Performance
-
Delivers an additional 20–25% energy from the rear side under high albedo conditions
📉 Degradation & Warranty
-
First-year degradation: ≤1.0%, and ≤0.4% annually from year 2–30
-
Warranties: 15-year product coverage; 30-year performance guarantee (≥87.4% output at year 30)
🛡️ Reliability Features
-
PID-resistant, low BOS cost, high quality (ISO 9001/14001/45001 certified), and backed by Tier‑1 insurer
✅ Ideal Applications
Well-suited for commercial rooftops, utility-scale solar farms, and industrial installations where maximum power, long lifespan, and resilience to adverse weather are priorities.
